VirtexTM UltraScale+TM System on Module
VirtexTM UltraScale+TM System on Module
- VirtexTM UltraScale+TM FPGA with B2104 Package
- Dual 4GB DDR4 (64-Bit) with ECC for FPGA
- 2GB DDR4 for FPGA (32bit)
- 76 channels of GTY transceivers up to 32Gbps
- 120 LVDS/ 240 SE FPGA Ios
- OSM module with Size-M
Documents
| Features | Details |
|---|---|
| VirtexTM UltraScale+TM SoC SoM | VirtexTM UltraScale+TM FPGA with B2104 Package Compatible with:
Up to 3,780K Logic cells & 1,728K LUTs |
| PMIC | Dual Dialog’s DA9062 PMIC |
| Memory & Storage | Dual 64bit, 4GB DDR4 with ECC for FPGA |
| OSM Features | Dual 64-bit Arm Cortex-A72 microprocessor at 2.0 GHz |
| FPGA to OSM Interfaces | PCIe x2 Gen3 |
| Other Interfaces | TPM2.0 module |
| Board to Board Connector1 Interfaces (400pin) | 120 LVDS/ 240 SE FPGA Ios |
| Board to Board Connector2 Interfaces (400pin) | From VU13P Interface
From OSM Interface
|
| Board to Board Connector3 Interfaces (400pin) | FPGA GTY Transceiver x 48 up to 32Gbps¹ |
| General Features |
|
