Solution Highlights
- Glass-to-glass latency under 66ms (FPGA-based) and under 100ms (FPGA + GPU)
- Multi SoM Architecture
- ZU7 MPSoC , NVIDIA Jetson Orin NX, and i.MX95 SMARC
- Custom Carrier Card to integrate all SoM and required processing
- High-Resolution Video supporting single-stream capture, compression, and loop-out up to 4Kp60 and 1080p60.
- Simultaneous encrypted streaming over dual Wi-Fi 6E/7 and wired 1GbE/10G SFP+
- Active cooling with PWM fans in a custom 300mm x 160mm x 50mm enclosure
iWave Scope of Work
Custom Carrier Card and Hardware Integration:
End-to-end design, simulation, fabrication, and assembly of 10 engineering sample units.
FPGA:
Separate binaries for different configurations featuring video subsystems, QDMA, and R5 applications.
Software and BSP Support:
Linux (6.1), BSPs, U-boot, and GStreamer porting across platforms, including GPU shader overlays.
Acceptance Testing:
High-Level Acceptance Test Plan (ATP) validation and pre-compliance EMI/EMC testing.
