NVMe Host Controller IP Core

Name: NVMe Host Controller
Brand: iWave Global
Availability: InStock

iWave’s NVMe Host Controller IP Core is compliant with the NVM Express base specification revision 1.4, enabling seamless memory transfers to and from NVMe storage devices . iWave’s NVMe Host Controller IP Core uses internal memory as data buffer, external DDR is used in the data path for the applications that does not accept any data backpressure. IP Core interfaces via PCIe, making it ideal for high-performance, large-capacity storage applications. The core features an AXI4-Lite interface for control and status register access and an AXI-Stream interface for data transfer.

CONTACT SALES

Documents

Brochure
Storage IP Cores ebook
Datasheet
Resource utilization
Performance report

Xilinx Evaluation Kit

Xilinx ZCU111 development kit (XCZU28DR-2FFVG1517E)
iW-RainboW-G30D (XCZU5EV-FBVB900-1-I)
iW-RainboW G35D (XCZU19EG-FFVC1760-2-I)
iW-RainboW-G35P (XCZU19EG-FFVC1760-1-I)
Xilinx Versal VEK 280 (XCVE2802-2MSEVSVH1760)
KCU105 Xilinx Evaluation Platform (xcku040-ffva1156-2-e)

Altera Evaluation kit

iW-RainboW-G43D Agilex 7 (R31B/C) (AGIB027R31B1E1V)
Intel Arria 10 SX development Kit (10AS066N3F40E2SG)

Features

Details

NVMe Host

Compliant with NVM Express base specification revision 1.4
Admin Command Supported:
1. SMART/Health information
2. Identify Controller data Structure
3. Identify Namespace data structure
4. Secure Erase
5. Shutdown command

for efficient NVMe device management.

NVM Command Supported:
1. Write Command
2. Read Command
3. Flush command

for reliable and high-performance data transfer.

Operates with LBA Size of 512 Bytes and 4K Bytes
Operates with Vendor specific PCIe Hard IP as a physical layer to access NVMe SSD
User data interface: AXI4 – Stream
User control interface: AXI4- Lite

Highlights

Includes on chip buffer for data buffering
Supports sustained workloads using DDR buffering in the data path
Supports debug & performance monitoring registers.
The iWave NVMe IP core is tested with multiple SSDs from multiple vendors with different controllers ensuring compatibility and robust performance across a diverse range of storage solutions.
