ADC & DAC PCIe Card Powered by RFSoC ZU49/ZU39/ZU29DR
iG-G42P®
- AMD Zynq™ UltraScale+™ RFSoC PCIe Card based on ZU49/ZU39/ZU29DR devices
- 16-Channel RF DAC up to 9.85GSPS for Signal Generation
- 16-Channel RF ADC up to 2.5GSPS for Data Acquisition
- 16 × GTY High-speed Transceivers up to 28.21Gbps
- ¾-Length PCIe x8 up to Gen4 High-Bandwidth Host Interface
Documents
Documents
Design Support
Software
| Features | Details |
|---|---|
| Zynq™ Ultrascale+™ RFSoC ZU49DR/ZU39DR/ZU29DR | Processing System (PS/Processor)
16 x DAC Ports support max date up to @9.85Gsps |
| RAM Memory | 8GB, 64bit DDR4 RAM with ECC for PS 8GB, 64bit DDR4 RAM for PL |
| Flash Memory | 256MB QSPI Flash for Booting 32GB eMMC Flash for Storage Micro SD slot from PS M.2 NVMe Slot from PS with PCIe Gen2 x2 x4 interfaces |
| ADC Channels (x16) | 1 x Right Angle SMA connector on Front Panel with Balun (BW 10MHz to 3GHz) 3 x Right Angle SMA connectors on Front Panel with Balun (BW 3.1GHz to 5.8GHz) 3 x Straight SMA connectors with Balun (BW 10MHz to 3GHz) 9 x Straight SMA connectors with Balun (BW 3.1GHz to 5.8GHz) |
| DAC Channels (x16) | 1 x Right Angle SMA connector on Front Panel with Balun (BW 10MHz to 3GHz) 3 x Right Angle SMA connectors on Front Panel with Balun (BW 3.1GHz to 5.8GHz) 3 x Straight SMA connectors with Balun (BW 10MHz to 3GHz) 9 x Straight SMA connectors with Balun (BW 3.1GHz to 5.8GHz) |
| Clock & PLL | Integrated Configurable ultra-low noise PLL for ADC & DAC Fully Configurable Clock Synthesizer with SyncE and PTP support 4 x SMA Straight connector for clocks (10MHz IN, 1PPS IN, Synchronous Clock In & Out) |
| Host Interface | PCIe Gen4 (Up to )x 8 Edge Connector |
| Expansion | FMC+ High serial Pin connector (HSPC) Connector 8 channel GTY Transceivers @ up to 28.21Gbps 2 GTY Reference Clock 48 LVDS IOs/96 Single ended (SE) IOs from PL Banks |
| Others | Two RJ45 1GbE Ethernet Port on Back Panel from PS Display port through USB-Type-C connector from PS RTC Battery Header 4 x GPIO SMA Straight Connectors |
| Debug | Integrated JTAG Programming/Emulator Module USB TypeC Debug Port on Front Panel for PS Debug UART, DATA UART and JTAG |
| Thermal | Fan sink (by default) |
| Operating Temperature | -30°C to +85°C (Industrial) |
| Power | 75W max from PCIe x 8 Host 8Pin ATX Power Connector in Back Panel Power Droop Sharing (to maximize power when needed) Power dissipation is application dependent |
| Form Factor | 254mm x 111.15mm (¾ Length PCIe) |
| Compliance | RoHS Compliant REACH Compliant CE* |
