Rugged Telematics Device
iG-G26I®
- Powered by i.MX 6ULL Micro-Processor
- 3 CAN Ports: CAN FD/HS CAN
- Integrated Hardware Secure Element
- Wireless Connectivity: LTE Cat 4, LTE Cat M1, Wi-Fi 5 and Bluetooth 5.0
- Ethernet, USB, Digital Inputs, Digital Outputs & Analog Inputs, RS232, RS485
- IP67 protection class
- LINUX 5.15 BSP with software flexibility
- Certification: CE/FCC/ISED/PTCRB/AT&T
- Ideal for telematics applications in rugged and off highway vehicles
Documents
Software
Mechanical
| Features | Details |
|---|---|
| Processor Core | CPU: NXP i.MX 6ULL MCU: NXP LPC 804 RAM: 512MB DDR3L SDRAM (Expandable up to 1GB) FLASH: 8GB eMMC Flash (Expandable up to 16GB) |
| Wireless Communication | Cellular: 4G LTE Cat 4/Cat M1 Wi-Fi 802.11a/b/g/n/ac Bluetooth: BLE 5.0 |
| Interfaces | CAN: 3 Ports (HS CAN x 2, CAN FD x 1) Ethernet: 10/100Mbps x 1 port (10BASE-T/100BASE-TX) 2 x Digital Inputs 2 x Digital Outputs 2 x Analog Inputs 1 x USB OTG 1 x RS2321 / 1 x RS4851 / 1 x K-Line1 |
| GNSS | GPS/GLONASS/BeiDou/Galileo |
| Sensors | Accelerometer and Gyroscope Magnetometer and Temperature |
| Antenna | SMA Connectors: 1 x LTE Primary, 1 x LTE Diversity¹, 1 x GNSS RP-SMA Connector: 1 x Wi-Fi/BT |
| Security Module¹ | Integrated Hardware Secure Element Crypto-Automotive Security IC Microchip TA100 |
| Power Characteristics | Power: 9V – 32V Stand-by Mode: 10mA Deep Power Down Mode: 1.2mA |
| Internal Battery | 1500mAh Lithium-ion Polymer |
| RTC | Dedicated RTC (Powered by internal Lithium-Ion polymer Battery) |
| Temperature Support | Operating Temperature: -40°C to +70°C² Storage Temperature: -40°C to +85°C² |
| Software | Operating System: Linux 5.15 Protocols: Socket CAN, ISO 15765-4, CANopen, J1939, UDSonCAN, UDSonIP |
| Security Suite1 | Secure boot / Secure storage OS hardening Wi-Fi Security |
| Enclosure | Dimension: 140 x 124 x 45mm Protection Class: IP67 Mounting Options: Panel mount |
| Certification | CE, FCC, ISED, PTCRB, AT&T |
Note:
¹ Optional features: For more information, please contact iWave sales team at mktg@iwave-global.com
² Temperature range subject to use case and operational functionality
Differences between the G76P EdgePrime and G26I Rugged Telematics Device
Key Feature Differences:
- Processor: i.MX93 Dual core processor in G76P vs IMX6ULL in G26I
- CAN Interfaces: 4× CAN FD in G76P vs 1× CAN FD & 2× HS CAN in G26I
- Ethernet: 100BASE-T1 automotive ethernet in G76P + standard 100Mbps ethernet
- Variants (SKUs):
- CAT-4 Global variant
- 5G RedCap Global variant
- Wireless: Wi-Fi 6 & BT v5.3 in G76P vs Wi-Fi 5 & BT v5.0 in G26I
- Serial Interface: 1× RS232 supported by default
FAQs
Yes, We have our Library which retrieves the data from the Hardware. Using this, you can develop your own application.
Telematics library provided is written in C language and is provided to the customer as a shared object file. We have customers who have developed their application in Python, Java using our library.
We do offer custom application development tailored to your specific requirements. Please share the protocol supported and DBC file for our understanding. We can check the feasibility based on DBC file.
We will be providing this solution based on customization. Any cloud platforms like Amazon AWS, IBM Watson, Microsoft Azure as per the requirement using MQTT, HTTPS, SFTP & TCP/IP Protocols (based on whatever protocol is supported by the cloud platform).
FOTA will be a customization feature at add on costs. We have also successfully integrated and demonstrated Mender/OSTree FOTA functionality.
For the evaluation kits customer has to purchase and install the SIMs. In production, customer has to ship the SIM and we will integrate and test the basic functionalities of the SIM.
Evaluation kits will come with Micro SIM slot. Device has the option for either Micro or eSIM option. Customer to provide the eSIM to iWave and based on the MoQ this can be done.
Our device has an micro-fit connector which is attached to the OBD Port through a harness cable.
Buy now
| Description | Stock | Order link |
|---|---|---|
| Rugged Telematics Device (LTE Cat-M1/ Global) | Backorder | Digikey |
| Rugged Telematics Device (LTE Cat-4 EMEA / APAC) | 2 | Digikey |
| Rugged Telematics Device (LTE Cat-4 NA / Canada) | 4 | Digikey |
| Rugged Telematics Device (LTE Cat-4 EMEA / APAC) | 2 | Mouser |
| Rugged Telematics Device (LTE Cat-4 EMEA / APAC) | 2 | Mouser |
| Rugged Telematics Device (LTE Cat-4 NA / Canada) | 1 | Mouser |
