NVIDIA® THOR Series
Jetson T5000 SoM |
- CPU
• 14-core Arm® Neoverse®-V3AE 64-bit CPU
• 1 MB L2 cache per core
• 16 MB Shared System L3 Cache
- GPU
• 2560-core NVIDIA® Blackwell architecture GPU with fifth-gen Tensor Cores
• Multi-Instance GPU (MIG) with 10 TPCs
|
| FPGA |
• High-performance FPGA with over 200K programmable logic cells
• Integrated 12 multi-gigabit serial transceivers and 20 user-programmable 1.8V-tolerant I/O pins
|
| Memory |
- RAM
• 128 GB 256-bit LPDDR5X on SoM
• 1 GB LPDDR4 on FPGA
- ROM
• 256 GB NVMe Memory connected to SoM
• 128 MB NOR flash for FPGA
|
| 3U VPX Back Panel |
VPX Connector: VITA 46 compliant 3U VPX interface
• PCIe Gen4 x8 interface for high-bandwidth VPX data fabric connectivity
• 4 × 25GbE Ethernet interfaces for high-speed networking and sensor data distribution
• 12 FPGA high-speed transceivers supporting ARINC 818, SDI, HDMI, Aurora, PCIe, Ethernet, and other high-speed serial protocols.
• 1 × Gigabit Ethernet management interface
• DisplayPort output through the VPX backplane (if routed via backplane; otherwise move to Front Panel Interfaces)
• IPMB interface for VPX system management and health monitoring
• 12V Power Input from the VPX backplane
• Utility Plane support for reset, clock, and platform management signals
|
| On Board Feature |
• 1GbE Ethernet on the front panel
• Board monitoring, reset sequencing, and health management
• Reset and clock synthesizer, Temperature sensors and voltage monitoring ICs
• One-wire Authenticator and Power Good, Reset LEDs on board to monitor board health
|
| General Feature |
• Slot Pitch: 1 Inch Conduction Cooled
• Power Supply: +12VDC +/- 5% input from VPX Connector
• Operating Temperature: -40°C to +71°C
• Form Factor: 3U VPX (100mm X 160mm)
• Environment Specification: RoHS and REACH
|
| Operating System |
|
| Target Application |
• Intelligence, Surveillance & Reconnaissance (ISR)
• Electronic Warfare (EW) Systems
• Avionics Video & Display Processing
|
