Telematics Edge capture
iG-G76C®
- Powered by i.MX 93 Micro-Processor Arm Cortex-A55 Cores
- 4 CAN-FD Ports
- Integrated Hardware Secure Element
- Wireless Connectivity: Upgrade Option to 5G RedCap (3GPP R17) LTE Cat 4, Wi-Fi 802.11 & Bluetooth 5.3
- Standard & Automotive Ethernet, Digital Inputs, Digital Outputs, Analog Inputs, RS232, RS485
- IP67 protection class
- LINUX 6.6.52 BSP with software flexibility
- GMSL2 Camera 3MP, LVDS Display along with touch1
- Ideal for fleet management, off-highway telematics, EV intelligence, and predictive analytics
Documents
Software
Mechanical
| Features | Details |
|---|---|
| Processor Core | CPU: NXP i.MX 93 Micro-Processor Arm Cortex-A55 Cores MCU: NXP LPC 804 RAM: 1GB LPDDR4X (Expandable up to 2GB) FLASH: 8GB eMMC Flash (Expandable up to 64GB) |
| Wireless Communication | Cellular: Upgrade Option to 5G RedCap (3GPP R17)1, LTE Cat 4 Wi-Fi 802.11a/b/g/n/ac/ax Bluetooth: BLE 5.3 |
| Interfaces | CAN: 4 CAN-FD Ports Standard Ethernet: 100Mbps x 1 port (100BASE-TX) Automotive Ethernet: 100Mbps x 1 port (100BASE-T1) 2 x Digital Inputs 2 x Digital Outputs 2 x Analog Inputs 1 x Ignition Input 1 x RS232 1 x RS4851 GMSL Camera 3MP1 |
| GNSS | GPS/GLONASS/BeiDou/Galileo |
| Sensors | Accelerometer, Gyroscope, Magnetometer |
| Camera | Resolution :3MP Port: 1 Connector: Fakra GMSL 2 Link Rate:6Gbps |
| Display1 | Type: LVDS Size: 7 inch (Expandable up to 10.1 inch) Resolution: Pixels (1024 x 600) |
| Antenna | External Fakra Connectors
|
| Security Module | Integrated Hardware Secure Element Crypto-Automotive Security IC Microchip TA100 |
| Power Characteristics | Power: 9V – 32V Stand-by Mode: 10mA Deep Power Down Mode: <1.5mA |
| Internal Battery | 1500mAh Lithium-ion Polymer |
| Temperature Support | Operating Temperature: -40°C to +70°C² Storage Temperature: -40°C to +85°C² |
| Software | Operating System: Linux 6.6.52 Protocols¹: Socket CAN, ISO15765-4, CAN open, J1939, UDSonCAN, Display with touch and camera |
| Security Suite1 | Secure boot / Secure storage |
| Enclosure | Dimensions:
Protection Class: IP67 |
Note:
¹ Optional features: For more information, please contact iWave sales team at mktg@iwave-global.com
² Temperature range subject to use case and operational functionality
