Kintex™ UltraScale+™ Gen2 2KU050P/40P/30P System on Module
iG-G88M®
- Kintex™ Ultrascale+™ Gen2 family with SSVA1440 Package
- Compatible with 2KU050P/40P/30P Devices
- RAM Bandwidth: x2 32-bit 4GB LPDDR5x for PL
- X2 256Mb QSPI Flash is supported
- 2KB EEPROM is supported
- 2KB FRU EEPROM is supported
- Up to 491K Logic cells & 225K LUTs
- 24 x PL GTY high-speed transceiver Lanes Upto 32.75 Gbps
- 312 SE IOs are supported
- Open Harmonized FPGA Module(oHFM) Form Factor: 50mm x 75mm(oHFM.c SizeL)
Documents
| Features | Details |
|---|---|
| Kintex™ Ultrascale+™ Gen2 2KU050P/40P/30P | 2KU050P/40P/30P Programming Logic (PL)
|
| Memory | 4GB LPDDR5X x2 256MB QSPI Flash memory x2 2kb EEPROM 2kb FRU EEPROM |
| Storage | 256MB QSPI Flash 2KB EEPROM 2KB FRU EEPROM |
| Three 340pin High Speed Board to Board Connectors Interfaces | From PL Block: Board to Board Connector 1
Board to Board Connector 2
Board to Board Connector 3
|
| General Features |
|
- MCU
- 2KB FRU EEPROM
- 2 KB SOM EEPROM
- 256MB QSPI x2
- PCIEx8 Connector
- General purpose LEDs
- DIP Switch
- PMOD Connector
- 40Pin Header
- 2 SMA Connector
- FMC+ Connector
- Reset Switch
- RGMII Magjack1
- DEBUG UART
- JTAG
- Boot Select DIP Switch
- Operating Temperature: -20°C to +85°C
- Form Factor: 140mm x 170mm
