ARINC 818 Switch IP Core

  • Compliance - ARINC 818-2 Specification
  • Channels - Up to 12 x 12
  • Link Rate - FC 1x, 2x, 3x, 4x
  • Progressive Video Format up to Full HD @ 60fps
  • Broadcast, Unicast, Multicast, Mixed Modes
  • Intelligent, Synchronous Switching of Video Frames
  • Real-Time Control & Monitor Through Web Browser
  • Not Limited to Maximum Resolution and Completely Depends on FPGA Transceiver Speed.
CONTACT SALES

Documents

Documents

Xilinx Evaluation Kit

Intel Evaluation Kit

Microchip Evaluation Kit

Features Details
Hardware Specs
  • IP Compliant to ARINC 818-2 specification
  • Video TX and RX interface: Simple Streaming Interface
  • Link rate:
    • C 1x, 2x, 3x & 4x
  • Transmission Medium:
    • Optical or
    • 75-ohm, 100-ohm or 150-ohm Copper
  • Supported Pixel Format:
    • Monochrome
    • RGB
    • YCbCr
    • RGBA
  • Supported Video Format:
    • Progressive Scan
    • Interlaced
  • Intelligent, Synchronous switching of video frames and supported
  • Switching Modes:
    • Broadcast: One video information is directed to all or numerous video output
    • Unicast: A video information is sent from one point to another point
    • Multicast: A video data is diverted to at least two video outputs
    • Mixed: Client can reroute any video input to any video output
  • Real-time link Control & Monitor via AXI-4 lite interface
