ADC & DAC PCIe Card Powered by RFSoC ZU48/47/43/28/27/25DR
iG-G60P®
- AMD Zynq™ Ultrascale+™ RFSoC ZU48/ZU47/ZU43/ZU28/ZU27/ZU25DR
- Up to 8 DAC channels through SMA connector with 9.85Gsps
- Up to 8 ADC channels through SMA connector with 5Gsps
- Up to 8 integrated SD-FEC
- PL GTY High Speed Transceivers x 16 @28.21Gbps
- 3/4 Length PCIe Gen3 x 8 Host Interface
Documents
Documents
Design Support
Software
| Features | Details |
|---|---|
| SoC | Zynq™ Ultrascale+™ RFSoC ZU48/ZU47/ZU43/ZU28/ZU27/ZU25DR Processing System (PS/Processor)
PL GTY High Speed Transceivers x 16 @28.21Gbps |
| RAM Memory | 8GB, 64bit DDR4 RAM with ECC for PS (Expandable up to 16GB) 8GB, 64bit DDR4 RAM for PL (Expandable up to 16GB) |
| Storage | 256MB QSPI Flash for Booting 32GB eMMC Flash for Storage Micro SD slot from PS M.2 NVMe Slot from PS with PCIe Gen2 x2 or x4 interface |
| ADC Channels (Up to x8) | 1 x Right Angle SMA connector on Front Panel with Balun (BW 10MHz To 3GHz) Up to 3 x Right Angle SMA connectors on Front Panel with Balun (BW 3.1GHz To 5.8GHz) 1 x Straight SMA connectors with Balun (BW 10MHz To 3GHz) Up to 3x Straight SMA connectors with Balun (BW 3.1GHz To 5.8GHz) |
| DAC Channels (Up to x8) | 1 x Right Angle SMA connector on Front Panel with Balun (BW 10MHz To 3GHz) Up to 3 x Right Angle SMA connectors on Front Panel with Balun (BW 3.1GHz To 5.8GHz) 1 x Straight SMA connectors with Balun (BW 10MHz To 3GHz) Up to 3x Straight SMA connectors with Balun (BW 3.1GHz To 5.8GHz) |
| Clock & PLL | Integrated Configurable ultra-low noise PLL for ADC & DAC Fully Configurable Clock Synthesizer with SyncE and PTP support 4 x SMA Straight connector for clocks (10MHz_IN, 10MHz_OUT, 1PPS IN, Synchronous Clock_IN) |
| Host Interface | Up to PCIe Gen4 x 8 Edge Connector |
| Expansion | FMC+ High serial Pin connector (HSPC) Connector 8 channel GTY Transceivers @ up to 28.21Gbps 2 GTY Reference Clock 48 LVDS IOs/96 Single ended (SE) IOs from PL Banks |
| Others | 2 x RJ45 1GbE Ethernet Port on Back Panel from PS Display port through USB-Type-C connector from PS RTC Battery Header |
| Debug | Integrated JTAG Programming/Emulator Module USB TypeC Debug Port on Front Panel for PS Debug UART, PL DATA UART and JTAG |
| Thermal | Fan sink (by default) |
| Operating Temperature | -40°C to +85°C (Industrial) |
| Power | 75W max from PCIe x 8 Host 8Pin ATX Power Connector in Back Panel Power Droop Sharing (to maximize power when needed) Power dissipation is application dependent |
| Form Factor | 254mm x 125.31mm (¾ Length PCIe*) |
