Zynq™ UltraScale+™ ZU19/ZU17/ZU11EG MPSoC SmartNIC Storage Accelerator Card
iG-G35P®
- ZU19/17/11 Zynq™ UltraScale+™ (Quad A53+FPGA)
- Up to 1143K Logic cells & 522K LUTs
- Dual Front Panel QSFP-DD/QSFP28 Cages (200GbE/100GbE)
- Single Front Panel QSFP-DD/QSFP Cages (40GbE/10GbE)
- 3/4 Length PCIe Gen3 x16 Host Interface
- Two M.2 NVMe Slots (High Performance Storage)
Documents
Documents
Design Support
Software
| Features | Details |
|---|---|
| ZU19/ZU17/ZU11 – Zynq™ UltraScale+™ MPSoC | Processing System (PS/Processor)
Programming Logic (PL/FPGA)
|
| RAM Memory | PS: 64bit, 8GB DDR4 RAM with ECC (expandable up to 32GB) PL: Dual 64bit, 8GB DDR4 RAM (expandable up to 16GB) |
| On Board Flash | 8GB eMMC Flash for Boot & OS storage (expandable up to 128GB) Micro SD Slot |
| Host Interface | PCIe Gen4 x 16 |
| High Speed Network | Dual Front Panel QSFP-DD Cages
Single Front Panel QSFP-DD Cage
|
| High Performance Storage | Dual M.2 NVMe Slot with PCIe Gen4 x 4 interfaces |
| Time Synchronization | Silicon Lab’s Si5389 IEEE 1588v2 1 PPS Input/Output through front panel SMA 10MHz Clock Input through front panel SMA SyncE Phase & Frequency Synchronization |
| Debug | USB Type C Debug Port for PS in Front Panel RJ45 1GbE Ethernet for PS in Back Panel Dual Stack LED in Front Panel |
| Thermal | Dual width Active cooling (by default) Dual/Single width Passive cooling (Optional) |
| Operating Temperature | -40°C to +85°C (Industrial) |
| Power | 75W max from PCIe x 16 Host 8Pin ATX Power Connector in Back Panel Power Droop Sharing (to maximize power when needed) Power dissipation is application dependent |
| Form Factor | 218mm x 111.15mm (¾ Length PCIe) |
| Compliance | RoHS Compliant REACH Compliant CE* |
