| Video Interface |
- Supports single/ Dual channel ARINC 818-2 video reception and transmission.
- Resolution & Frame Rates: Up to UHD @30FPS / 2K @60FPS per channel.
- Link rates: 1x, 2x, 3x, 4x, 5x, 6x, 8x, 10Gbps.
- Uncompressed video capture and transmission.
- SFP-based optical/Copper interface for high-speed ARINC 818 video transmission/Reception.
- Supports flexible configurations such as single/dual
- ARINC 818 Inputs to Host PC
- ARINC 818 inputs to HDMI outputs
- HDMI inputs to ARINC 818 outputs, depending on user requirements.
|
| Host Interface |
- PCIe Gen 3, x8 lane with a total maximum theoretical bandwidth of 64Gbps.
- Total onboard memory bandwidth of up to 192 Gbps.
- Full-Height Half-Length PCIe form factor, suitable for integration into Host PC systems.
|
| Software Feature |
- Compatible with Linux operating system using V4L2 framework driver
- Supports video node detection for automatic Video Device recognition for applications like VLC media, OBS studios and more.
- Supports Application like Gstreamer and FFmpeg.
- ARINC 818 receiver data capture from the PCIe card to the host PC.
- Automatic detection of ARINC 818 video resolution and frame rate on the host.
- Dynamic ARINC 818 transmitter configurations with standard or custom resolution based on ICD.
- Dynamic ARINC 818 transceiver link rate control from the host PC.
- Configurable ARINC 818 transmitter settings, including resolution,
frame rate, pixel clock, sync timings, front and back porch, color format, and SOF class.
- Support for real-time video data streaming from the host PC to the ARINC 818 transmitter.
|
| Highlights |
- Handles multiple resolutions and refresh rates up to UHD @30FPS or 2K @60FPS.
- PCIe Gen 3 x8 lane with a total maximum theoretical bandwidth of 64Gbps.
- ARINC 818 to HDMI and HDMI to ARINC 818 Conversion supported.
- Full-Height Half-Length PCIe form factor, suitable for integration into Host PC systems.
- Compatible with Linux OS for flexible deployment.
- Supports video node detection for applications like VLC media, OBS studios and more.
|
