Telematics Gateway
iG-G41G®
- Powered by i.MX 8XLitePowered by i.MX 8XLite Micro-Processor
- 5 CAN FD ports
- Integrated Hardware Secure Element
- Wireless Connectivity: LTE Cat 4, 5G Upgrade option, Wi-Fi 6 and Bluetooth 5.3
- Standard & Automotive Ethernet, RS232, RS485, Digital Inputs, Digital Outputs & Analog Inputs
- High precision GNSS Module
- IP67 Protection class
- LINUX 6.1.22 BSP and API for peripherals
- Ideal for Heavy Duty Vehicles, Waste Disposal Truck, Cleaning & Industrial Machines
Documents
Software
Mechanical
Certifications
| Features | Details |
|---|---|
| Processor Core | CPU: NXP i.MX 8X Lite Micro-Processor MCU: NXP LPC 804 RAM: 2GB LPDDR4 FLASH: 8GB eMMC Flash (Expandable up to 128GB) |
| Wireless Communication | Cellular: LTE Cat 4 / 5G Wi-Fi 802.11a/b/g/n/ac/ax Bluetooth v5.3 |
| Interfaces | CAN: 5 x Ports (CAN FD) Ethernet: 1 x 100BASE-TX [Fast Ethernet], 1 x 100BASE-T1[Automotive Ethernet] 2 x Digital Inputs 2 x Digital Outputs 2 x Analog Inputs 1 x RS232 1 x RS485 1 x K-Line/LIN¹ |
| GNSS | High precision GNSS1: GPS/BeiDou/Galileo/SBAS/QZSS/AGNSS GNSS: GPS/GLONASS/BeiDou /Galileo |
| Sensors | Accelerometer, Gyroscope, Magnetometer |
| Antenna | SMA Connectors: 1 x LTE Main, 1 x LTE diversity, 1 x GNSS RP-SMA Connectors:1 x Wi-Fi, 1 x BT |
| Security Module | Integrated Hardware Secure Element Crypto-Automotive Security IC Microchip TA100 |
| Power Characteristics | Power: 9V – 32V Stand-by Mode: 20mA Deep Power Down Mode: 2mA |
| Internal Battery | 1500mAh Lithium-ion Polymer |
| RTC | Dedicated RTC (Powered by internal Lithium-Ion polymer Battery) |
| Temperature Support | Operating Temperature: -40°C to +85°C² Storage Temperature: -40°C to +85°C² |
| Software | Operating System: Linux 6.1.22 Protocols¹: Socket CAN, ISO 15765-4, CANopen, J1939, UDSonCAN, UDSonIP, K-Line |
| Security Suite1 | Secure boot / Secure storage Wi-Fi Security |
| Enclosure | Dimension: 203 x 160 x 46mm Protection Class: IP67 with tamper detection Mounting Options: Panel mount |
Note:
¹ Optional features: For more information, please contact iWave sales team at mktg@iwave-global.com
² Temperature range subject to use case and operational functionality
