ARINC 818-2 IP Core

  • Compliance - ARINC 818-2 Specification
  • Video Resolution – 4K @ 30fps
  • Video TX & RX - Simple Streaming Interface.
  • Implemented on any Transceiver-Based FPGA
  • Pixel Format - Monochrome, RGB, YCbCr, RGBA
  • Single stream or Multi stream support over single OFC link
  • Transmission Medium–Optical or 75-ohm Copper
  • Customize Customer's ICD and Deliver Within 3-4 Weeks
CONTACT SALES

Documents

FeaturesDetails
Hardware Specs
  • IP Compliant to ARINC 818-2 specification
  • Video TX and RX interface: Simple Streaming Interface
  • Custom data transmission & reception during the video blanking period
  • Transmission Medium
    • Optical or
    • 75-ohm, 100-ohm or 150-ohm Copper
  • Link Rate Supported
    • FC 1x, 2x, 3x, 5x, 6x, 8x & 12x
  • Video Resolution Supported
    • Resolution up to 4K @ 60fps
  • Video Type
    • Progressive Scan
    • Interlaced
  • Pixel Format supported
    • Monochrome
    • RGB
    • YcbCr
    • RGBA
  • Pixel Aspect ratio supported.
    • 1:1
    • 1:1.2
    • 1.2:1
    • NTSC (approx 8:9)
    • PAL (16:15)
  • Frame Rate supported.
    • 15fps
    • 20fps
    • 24
    • 24 * 1000 / 1001
    • 25 (PAL)
    • 30
    • 30 * 1000 / 1001 (29.97 NTSC)
    • 60
    • 50
    • 60 * 1000 / 1001 (59.94 NTSC)
    • 50 (VESA DMT)
    • 60 (VESA DMT)
    • 75 (VESA DMT)
    • 85 (VESA DMT)
    • 50 (VESA CVT)
    • 60 (VESA CVT)
    • 75 (VESA CVT)
    • 85 (VESA CVT)
  • Pixel Table Number supported
    • 8-bit Components, four components per transmission word
  • Pixel Array Order supported
    • Left to Right, Top to Bottom
  • Line Synchronous Mode supported
  • User-configurable parameters as per ICD requirement
    • No. Of rows
    • No. Of Columns
    • Video Format Code
    • Pixel Aspect Ratio
    • Video Frame rate
    • Color Information Code

iWave’s ARINC 818-2 IP Core is CEH / DO-254 Compliant and CEMILAC Certified, demonstrating adherence to stringent aerospace and defence design assurance, reliability, and quality standards. These certifications reinforce the IP core’s suitability for mission-critical avionics and high-performance video interface applications.

CEH / DO-254 Certified

CEH / DO-254 Certified

CEMILAC Certified

CEMILAC Certified


Product Design Process

Our design process transforms your vision into reality with innovation, quality, and collaboration.

Learn More


Certification & Qualification

Ensuring Compliance, Quality, and Trust Through Certification & Qualification.

Learn More


Product Lifecycle Management

Ensuring Longevity, Reliability, and Seamless Product Evolution.

Learn More


Mechanical Services

Precision Engineering for Reliable, High-Performance Mechanical Solutions.

Learn More

FAQs

ARINC 818, also known as the Avionics Digital Video Bus (ADVB), is a standard for high-speed, low-latency, point-to-point video transmission in avionics systems. It carries uncompressed video, audio and data over a serial link, which is why it is widely used in cockpit displays, sensor video distribution and mission systems.

Unlike general-purpose video interfaces such as HDMI or DisplayPort, ARINC 818 is designed for avionics. It supports configurable Interface Control Documents (ICDs), so one standard can fit many different display and sensor requirements.

iWave offers ARINC 818 recorders, monitors, video conversion COTS products and analyzers. The portfolio also includes an ARINC 818-2 IP core that offers point-to-point, high-speed, low-latency video transmission and can be implemented on any transceiver-based FPGA device. Together these cover the full design-to-deploy cycle, from prototyping and integration to testing and fielding

ARINC 818-3 is the later revision of the standard and adds features such as improved support for higher line rates and additional functionality. ARINC 818-2 remains the version most widely deployed today. iWave provides both ARINC 818-2 and ARINC 818-3 solutions for aerospace applications. You can choose the revision your platform requires

The Interface Control Document (ICD) is the agreement between transmitter and receiver that defines how a given link behaves: resolution, frame rate, pixel format, link rate, how video is divided into containers and objects, and what ancillary data is carried. ARINC 818 is deliberately flexible, so two compliant devices will only interoperate if they are built to the same ICD. Most integration problems come from ICD mismatches, not protocol faults.

If the core goes into airborne electronic hardware that is subject to DO-254, you will need compliance evidence appropriate to the design assurance level (DAL) of the function. This is why many teams ask for IP delivered with certification support, such as requirements, verification results and traceability, rather than a bare netlist. Confirm what is included before choosing a core

Yes. Besides video, an ARINC 818 link can carry ancillary data and custom data, such as timing, status, files or sensor metadata, within the same frame structure. Multiple video streams can also be multiplexed over a single link, depending on the ICD and available bandwidth.
